Lower crankcase cover sub-assembly

SEGWAY
Výrobce: SEGWAY
Kód produktu: SEGWAY_1_112_UTV1000
Vybrat MODEL:
Fugleman UT10 Fugleman UT10
Ref. č Obr. Kód p. Popis Počet v daném rozkresu Cena za 1 ks dostupnost
1 LOWER CRANKCASE COVER GASKET (Ref. č 1) F02C50001001 LOWER CRANKCASE COVER GASKET  1 65,29 Kč 79 Kč
SKLADEM
9 BOLT M6×40 (Ref. č 9) F01000008001 BOLT M6×40  1 57,02 Kč 69 Kč
SKLADEM
8 BOLT M6×16 (Ref. č 8) F01000002001 BOLT M6×16  3 57,02 Kč 69 Kč
SKLADEM
7 OIL COOLER ASSEMBLY (Ref. č 7) F02G21000001 OIL COOLER ASSEMBLY  1 1 147,93 Kč 1 389 Kč
NA DOTAZ
6 O-Ring 19×2.5 (Ref. č 6) F01G00007001 O-Ring 19×2.5  3 57,02 Kč 69 Kč
SKLADEM ZA 10 dnů
5 GASKET 14×21×1.5 (Ref. č 5) F01F10003001 GASKET 14×21×1.5  1 93,39 Kč 113 Kč
SKLADEM
4 WATER PIPE ADAPTER (Ref. č 4) F01H00008001 WATER PIPE ADAPTER  1 175,21 Kč 212 Kč
SKLADEM
3 BOLT M6×25 (Ref. č 3) F01000005001 BOLT M6×25  12 57,02 Kč 69 Kč
SKLADEM
2 LOWER CRANKCASE COVER ASSEMBLY (Ref. č 2) F02C52000001 LOWER CRANKCASE COVER ASSEMBLY  1 738,02 Kč 893 Kč
NA DOTAZ
10 OIL AND GAS SEPARATOR (Ref. č 10) E02-C520004-000-01 OIL AND GAS SEPARATOR  1 77,69 Kč 94 Kč
NA CESTĚ
